Dlink DGS-F1026P-E 24GE PoE + 2 SFP Ports 250m PoE Switch

₹24,000.00

DGS-F1026P-E

Features twenty-four 10/100/1000 BASE-T ports that Support the IEEE 802.3af and IEEE 802.3at PoE protocols, supplying up to 30W on each PoE port and Port 1-8 can support up to 250m

24 10/100/1000 Mbps gigabit ethernet ports
2 SFP port
250watts available PoE
Flow control for protection against loss data
Maximum distance of 250m
Light protection (6kV)
Operating Temperature: 0 to 40 deg C (32 to 104 deg F)

Specifications

Size	Desktop (with Mounting Kit)
Network Interface	24 10/100/1000 BASE-T ports, 2 SFP
Standards	IEEE 802.3u, Fast Ethernet standards; IEEE 802.3af/at, Ethernet power supply POE standard; IEEE 802.3ab, Gigabit Ethernet standards; IEEE 802.3az, EEE, Energy efficient Ethernet standard; IEEE 802.3x, Full-duplex Ethernet data link layers ; IEEE 802.3z, Gigabit Ethernet fiber-optic standard
Media Interface Exchange	Auto MDI/MDI-X adjustment on all ports
Lightning protection	6KV
Switching Fabric	52 Gbps
Transmission Method	Adopt Store-and-forward
Data Transfer Rates	Gigabit Ethernet -1000 Mbps, Ethernet -100 Mbps
Physical specifications	Dimensions (LxWxH): 440 x 180 x 44mm, Weight: 3.0kg
POE Power Budget	250W (30 W max. per PoE port)
Power	Total Power: 250W
Humidity	Operating: 0% to 95% RH non-condensing, Storage: 0% to 95% RH non-condensing

SKU: F1026P Category: SWITCHES

Description

High Transmission distance

With high distance connectivity, ideal for surveillance solution. Can be used with cat5e or cat6 cable. The DGS-F1026P-E features 24 ports 10/100BASE-TX ports that support the IEEE 802.3af/at PoE protocol. With total power budget of 250W.

Plug & Play Installation

The DGS-F1026P-E is a Plug-and-Play device that requires no configuration, so setup is simple and hassle-free, and you can easily connect multiple computers, share files, music, and video across your home or small office network, or even create a multiplayer gaming environment. 802

.3x flow control on each port minimizes dropped packets when the port’s receiving buffer is full, giving you a more reliable connection for all of your connected devices.

Different Switch working mode

The DGS-F1026P-E switch works in 4 operating modes using DIP switch

Extend – 1-8 ports support up to 250m distance power supply
VLAN-Isolating ports 1-24 from each other can effectively suppress network storms and improve network performance
QoS-Prioritize the identified video data to make video transmission smoother
PoE-Automatic detection power of port, power off and restart
