| Network Interface |
8 10/100/1000Mbps PoE RJ45 port (port 1 ~port 8) , 2 10/100/1000Mbps uplink RJ45 port (port 9~port 10) |
| Transmission Rate |
10/100/1000Mbps Each port supports MDI / MDIX auto-flip and auto, Network interface:10BASE-T or 100BASE-TX Ethernet RJ-45 port |
| Protocols and Standards |
IEEE802.3i 10BASE-T, IEEE 802.3u 100BASE-TX, IEEE 802.3ab 1000BASE-T, ANSI/IEEE 802.3 NWay auto-negotiation, IEEE802.3x Flow Control, IEEE 802.3af/at standard |
| Performance |
Bandwidth: 20 Gbps (no block), Network delay (100 to 100M bps): maximum 20 μs (using 64byte packet), Frame filtering and transmission rate, 10M: 14,800pps, 100M: 148,800pps, 1000M: 1488,00pps |
| LEDs Indicator |
Power, LINK/ACT，POE |
| POE Pin |
1/2(+) 3/6(-) |
| Power |
Total Power: 120W |
| Lightning protection |
6KV |
| Physical specifications |
Dimensions (LxWxH): 184 x 94 x 27mm, Weight: 1.05kg |
| Environmental norms |
Operating Temperature: 0°~40°C Storage Temperature: -10°C~70°C, Operating Humidity: 10%~90% non-condensing, Storage Humidity: 5%~90% non-condensing |
| EMC |
CE Class B, FCC Part 15，Class B, VCCI Class B, C-Tick |
