Description
Specifications
| 1000Base-T Interface | 16 |
|---|---|
| Auto MDI/MDIX | Yes |
| Switching Capacity | 32Gbps |
| Max. Packet Forwarding Rate | 23.8 Mpps |
| Store & Forwarding Forwading | Yes |
| Dimension | 280 x 125 x 44 mm |
| Weight | 1.023 kgs |
| Operation Temperature | 0 ~ 40 °C |
| Storage Temperature | – 10 ~ 70 °C |
| Operation Humidity | 0% ~ 95% RH |
| Storage Humidity | 0% ~ 95% RH |
| Maximum Power Consumption | 10.07W |
| Standby Power Consumption | 3.02W |
| Maximum Heat Dissipation | 34.3 BTU/h |
| MTBF | 1,882,372 hours |
| Power Input | AC：100 ~ 240 V |
| Packet Buffer Size | 512KBytes |
| FAN | fanless |
| Comply with RoHS 6 | Yes |
| Energy Efficiency Ethernet (EEE) | Yes |
| Power Saving By Link Status | Yes |
| Power Saving By Cable Length | Yes |
| MAC Address Table Size | 8,192 |
| 802.3x Flow Control | Yes |
| Head-of-line (HOL) Blocking Prevention | Yes |
| Jumbo Frame | 10,000 Bytes |
| Surge/Lightning Protection (AC Power Inet) | 1kV |
| Surge/Lightning Protection (All Ethernet Ports) | 1kV |
| Air Discharge | 8kV |
| Contact Discharge | 4kV |
