Description
Specifications
| 1000Base-T Interface | 4 |
|---|---|
| 1000Base-T PoE Interface | 4 |
| Auto MDI/MDIX | Yes |
| Switching Capacity | 16 Gbps |
| Max. Packet Forwarding Rate | 11.90 Mpps |
| Store & Forwarding Forwading | Yes |
| Dimension | 150 x 98 x 28 mm (5.90” x 3.85” x 1.10 in”) |
| Weight | 0. 383kgs |
| Operation Temperature | 0 ~ 50 °C for device 0 ~ 40 °C for external power adaptor |
| Storage Temperature | – 40 ~ 70 °C |
| Operation Humidity | 0% ~ 95% RH |
| Storage Humidity | 0% ~ 90% RH |
| Maximum Power Consumption | 74.2 Watts |
| Standby Power Consumption | 0.26 Watts |
| Maximum Heat Dissipation | 41.602 BTU/h |
| MTBF | 1423889.87 |
| Power Input | 100-240V AC |
| Flash Memory Size | 512Kbits |
| Packet Buffer Size | 1.5Mbits |
| FAN | Fanless |
| Comply with RoHS 6 | Yes |
| Energy Efficiency Ethernet (EEE) | Yes |
| Power Saving By Link Status | Yes |
| Power Saving By Cable Length | Yes |
| Maximum PoE Budget | 60 W (30 W max. per PoE port) |
| MAC Address Table Size | 4K |
| 802.3x Flow Control | Yes |
| Head-of-line (HOL) Blocking Prevention | Yes |
| Jumbo Frame | 9216 Bytes |
